Dimension of Socket and Spigot Ends Ductile Iron Pipes – Thickness Class (Class K7 & K9)
| Nominal Dia of Pipe ‘DN’ | External Diameter 'DE' | Barrel Wall Thickness 'e' | |
| K7 & K9 | K7 | K9 | |
| mm | mm | mm | mm |
| 80 | 98 | 5.0 | 6.0 |
| 100 | 118 | 5.0 | 6.0 |
| 125 | 144 | 5.0 | 6.0 |
| 150 | 170 | 5.0 | 6.0 |
| 200 | 222 | 5.0 | 6.3 |
| 250 | 274 | 5.3 | 6.8 |
| 300 | 326 | 5.6 | 7.2 |
| 350 | 378 | 6.0 | 7.7 |
| 400 | 429 | 6.3 | 8.1 |
| 450 | 480 | 6.6 | 8.6 |
| 500 | 532 | 7.0 | 9.0 |
| 600 | 635 | 7.7 | 9.9 |
| 700 | 738 | 9.0 | 10.8 |
| 750 | 790 | 9.7 | 11.3 |
| 800 | 842 | 10.4 | 11.7 |
| 900 | 945 | 11.2 | 12.6 |
| 1000 | 1048 | 12.0 | 13.5 |
| 1100 | 1152 | 14.4 | 14.4 |
| 1200 | 1255 | 15.3 | 15.3 |
(Source: IS 8329:2000)
Properties of Ductile Iron Pipes
| Properties | Ductile Iron Pipes |
| Tensile Strength | Min. 420 MPa |
| Elongation at Break | 10% Max. |
| Hardness | 230 BHN |
| Elastic Co-efficient | 1.7 x 104 Kg/mm2 |
| Density | 7050 Kg/m2 |
| Bending Strength | Over 50 Kg/m3 |
| Yield Strength | 300 MPa |
